IPv6 General multicast address format (old) List of interfaces to which traffic might be forwarded because of hosts that are local members on that interface. List of interfaces that are included in the immediate outgoing interfaces for the corresponding (S,G,rpt) entry. List of interfaces that are included in the immediate outgoing interfaces for the corresponding (S,G) entry. List of interfaces that are included in the immediate outgoing interfaces for the corresponding (*,RP) entry. List of interfaces that are included in the immediate outgoing interfaces for the corresponding (*,*,RP) entry. List of interfaces that have (*,G) join and could trigger assert List of interfaces that have (*,G) join and will track assert List of interfaces that have (*,G) join and have assert-lost state List of interfaces that have (*,G) join and have assert-winner state
List of interfaces that are assert-lost state List of interfaces that are in assert-winner state List of interfaces that are in prune-pending state List of interfaces that are in prune state List of interfaces that are in joined state List of interfaces that have clients that originated (*.G) join List of interfaces that have clients that originated (*,*,RP) join Interfaces where are clients registered with (*.G) join Interface name list on which router is chosen as designated router Time-out when entry will be removed from the list. Join-register-state (joined | pruned | join-pending | unknown) Join-state (joined | not-joined | rpt-not-joined | rpt-pruned | rpt-not-pruned) Router interface that is toward the rendezvous pointĪddress of next router towards RP according to PIM RP tree Router interface receives data stream of the multicast group Multicast group that has at least one registered join request
Multicast forwarding cache - this section only provides information about current state of multicast cloud at given router, showing states of joins for multicast groups.
Group join list of all the group joins that are registered by PIM-SM
